Tesla Wolf v2

The JPTR FX Tesla Wolf v2 is an overdrive effects pedal designed with a range of features and specifications for versatile use. The pedal offers Volume, Gain, Tone, Clean Blend, and Boost controls, allowing for precise adjustment of the overdrive effect. It operates on a 9-18V DC power supply with a 2.1 mm centre-negative connector and has a power consumption of less than 50 mA. The pedal is housed in a standard-sized, all-metal die-cast enclosure with hand- screen printed graphics.

The Tesla Wolf v2 is equipped with internal adjustment options, including a Bass control for increasing low-end output and three internal dip switches for altering gain characteristics through the addition of diodes and LEDs in the circuit. These features make the pedal highly customizable, offering a wide range of tonal possibilities from vintage to modern overdrive and fuzz tones.

The pedal's dimensions are approximately 120 mm (length) x 65 mm (width) x 39 mm (height), and it weighs 262 g. It is designed to be compatible with tube amps and setups where pushing the next gain stage is desired. The pedal is known for its dynamic and touch-sensitive response, making it suitable for various playing styles and musical genres.

The pedal does not support battery power and is intended for use with a 9V centre-negative power supply.
