DT-1

The DT-1 by Nobels is a digital step sequencer pedal designed for precise control over sequencing and modulation effects. Here are the technical specifications and features:

- Power: 9V dry battery / AC adaptor
- Consumption: max. 11mA
- Input impedance: 1Mohm
- Output impedance: 2Kohm
- Max. input: +6dB
- Controls: Drive, Tone, Level
- Jacks: Input, DC, Remote, Output
- Remote: momentary switch
- Display: green LED indicator
- Dimensions: 74mm x 126mm x 58mm
- Weight: approx. 460g (without Battery)

Functionality:
- The IN jack switches the unit on when a plug is inserted.
- The 9V DC jack allows connection to a regulated 9V power supply unit.
- The REMOTE jack enables remote control of the ON/OFF function by a momentary switch.
- The OUT jack delivers a low impedance output signal suitable for the amplifier input.
- DRIVE control adjusts the distortion level from slight crunch to full overdrive.
- TONE control modifies the amount of treble frequencies.
- LEVEL control adjusts the volume.
- LED indicator shows the effect status.

Operation:
- Insert a 9V battery or connect a regulated 9V power supply adaptor.
- Connecting an instrument to the input jack automatically switches the unit on.
- Connect the amplifier to the output jack and adjust the desired sound using the control knobs.
- Pressing the pedal switches the unit on or off.
- The unit can be controlled remotely with a standard momentary footswitch connected to the remote jack.

Important notes:
- Avoid extreme humidity, heat, or dust environments.
- Remove the battery during extended periods of non-use to prevent leakage damage.
- Unplug the input to conserve battery life when the unit is not in use.

The DT-1 by Nobels offers precise control over distortion effects and is suitable for hard rock and heavy metal players.
