Tonebone Mix-Blender

The Radial Tonebone Mix-Blender is a versatile multi-function pedal designed for guitar, bass, and keyboards. It features two class-A buffered inputs with individual level controls, allowing users to mix two instruments or effects together and then send the combined signal through a footswitch-controlled effects loop for processing. The effects loop includes a unique wet/dry Blend control, enabling users to retain the original sound of the instrument and add in as much of the pedals as desired, for effects ranging from subtle to extreme.

Key Technical Specifications:
- Type: Dual Instrument Mixer with FX Loop
- Inputs: 2 x 1/4" (instrument), 1 x 1/4" (return)
- Outputs: 1 x 1/4" (out), 1 x 1/4" (send)
- Audio circuit type: Discrete Class-A main audio path Audio Grade IC send- return loop
- Frequency response: 20Hz - 20KHz +0/-2dB
- Dynamic range: (instrument input) 105dB, (FX loop) 100dB
- Input Impedance: -220k
- Equivalent Input Noise: -97dBu
- Maximum Input: +10dBu

Use-Cases and Applications:
1. Mixing two instruments for simultaneous output through the same amp.
2. Blending two pickups on an acoustic guitar for natural sound.
3. Adding overdrive or distortion to a bass guitar without losing the powerful bottom end.
4. Incorporating effects pedals with precise control to enhance the signal.

The Mix-Blender has received positive reviews for its seamless functionality and durability, making it a reliable choice for musicians seeking to blend instruments and effects with precision and control.
