DI600P Ultra-DI

The Behringer DI600P Ultra-DI is a high-performance passive DI (Direct Injection) box designed for stage and studio applications. Here are the technical specifications and features:

- Provides impedance and signal matching for the direct connection of instruments to mixers and amplifiers
- Ultra-flat frequency response due to the renowned BEHRINGER OT-2 transformer
- Allows direct connection to speaker outputs with up to 3,000 Watts
- Ground Lift switch eliminates typical ground loop problems
- Filter switch reduces annoying hiss and buzz
- Thru/Out jack lets you send the unbalanced signal to an onstage amplifier while the balanced signal is routed to the mixer
- ¼" TRS and gold-plated XLR connectors
- Ultra-rugged, road-suitable metal case
- High-quality components and exceptionally rugged construction ensure long life and durability
- Frequency response: 40 Hz (-3 dB) to 20 kHz
- THD+N (Distortion): 0.003% @ 1 kHz, input level +4 dBu
- Input: ¼" TS (unbalanced)
- Level change (input → output): -20 dB
- Output: Balanced XLR
- Impedance ratio (input → output): 110 : 1
- INST/AMP switch: 30 dB pad
- Filter switch: Low pass @ 7.5 kHz (-3 dB)
- Dimensions (H x W x D): 1.4 x 3.75 x 5" / 35 x 95 x 128 mm
- Weight: approx. 0.66 lbs / 0.3 kg

The DI600P is a versatile and reliable tool for connecting guitars, basses, keyboards, and other instruments directly to mixers, providing high-quality signal integrity and addressing common audio challenges.
