Avalanche Run by EarthQuaker Devices

The Avalanche Run by EarthQuaker Devices is a stereo reverb and delay pedal with the following features and technical specifications:

- Dimensions: 4.65 x 4.15 x 2.25 inches (118 x 105 x 57 mm) with knobs
- Current Draw: 410 mA
- Input Impedance: 1 MΩ
- Output Impedance: 100 Ω
- Signal-to-Noise Ratio: 115dB typical
- 24-bit 96kHz A/D & D/A converters
- All analog dry signal path
- All digital wet signal path with 20Hz – 20kHz frequency response
- Expression Jack: Located on the west side of the pedal, it is a TRS jack with the tip acting as the wiper. It is recommended to use a Moog expression pedal with the output adjustment knob all the way up. Other expression pedals are not guaranteed to work with the Avalanche Run.
- Flexi-Switch® Technology: This relay-based, true bypass switching style allows simultaneous use of momentary and latching style switching. For standard latching operation, tap the footswitch once to activate the effect and then tap again to bypass. For momentary operation, hold the footswitch down for as long as desired to use the effect. Once released, the effect will be bypassed. Since the switching is relay-based, it requires power to pass signal.
- Power: It is recommended to use the included 9v center-negative 1-amp DC power supply for best results.
- PCBs: Populated by a combination of artificial and human intelligence in Akron, Ohio, USA.
- Assembly: Each and every Avalanche Run is completely assembled, wired, and tested by humans in Akron, Ohio.

The pedal includes up to 2 seconds of delay time, reverse delay, tap tempo with subdivision control, switchable true bypass or buffered bypass with 5 different tail lengths, and an assignable expression control that maps the expression jack to a control of your choice, including the toggle. The delay section allows tweaking from tape emulation to bucket brigade styles with a twist of the wide-range Tone control. The cavernous, plate-style reverb has just a touch of modulation similar to the one found in the Dispatch Master, only more lush with an adjustable Decay. Otherworldly reverse delay and dynamic swelling reverb settings are accessible through a 3-way toggle switch.

The pedal also features controls for Time, Repeats, Tone, Mix, Expression Jack Assign Switch, Decay, R Mix, Time, Repeats, D Mix, Ratio Selector Switch, Decay, Toggle Switch (Mode Selector), and Mix.

The Avalanche Run offers various audio samples for guitar, bass, and synth, and supports mono, stereo, and mono in/stereo out configurations for different audio setups.
