OD-9

The Maxon OD-9 is a highly regarded overdrive pedal known for its classic TS-9 circuitry. It features true bypass switching for clean, uncolored tone when bypassed. The pedal has an input impedance of 500K Ohms and an output impedance of 10K Ohms or less. The maximum gain is 48.5 dB at 1.6 KHz, and the equivalent input noise is -106.8 dB or less (IHF-A).

The OD-9 has controls for TUBE, DRIVE, TONE, and LEVEL, allowing for precise tonal shaping and gain adjustment. It operates on 9V DC center negative power supply, with a power consumption of 6 mA. The internal circuit voltage is 30 VDC, achieved through a DC-DC converter. The pedal's dimensions are 74 mm (W) x 124 mm (D) x 54 mm (H), and it weighs 560 g (excluding AC adaptor).

The OD-9's design incorporates a mil-spec 5703WB JAN Raytheon sub-miniature vacuum tube positioned at the front of the audio path, driving the OD-9 circuit. This tube stage adds warmth, dimension, and increased saturation to the classic OD-9 tone, providing a big, natural-sounding bottom end and characteristic tube "sag."

The pedal features mechanical true bypass switching via a Fujisoku 4PDT switch, ensuring minimal tone coloration when the effect is disengaged. The Maxon OD-9 is a versatile overdrive pedal suitable for a wide range of musical styles and applications, offering classic tonality with the added warmth and saturation of a tube stage.
