Tunable Wah-Wah pedal

The Real McCoy Custom RMC3 is a fully tunable self-contained wah pedal, first created in 1994. It features the following interior Vari-Tune circuit controls:

1. LOW: Controls the amount of low frequencies present in the wah's sweep.
2. MID: Controls the mid-range depth of the sweep, affecting the vocal-like quality of the wah.
3. Q Harmonic: Controls the position of the sweet spot within the sweep range, replacing the 33K or 100K resistor in old Italian wahs.
4. VOLUME: Allows adjustment of the output strength of the wah.
5. SWEEP: A bank of 9 DIP switches that enable selection of the desired sweep within a 9 octave range, creating familiar wah sweeps as well as some never- before-available voicing parameters.
6. FINE TUNE: Two trimmers that work in conjunction with the SWEEP DIP switches to allow access to values "in-between" switch settings.

Technical specifications include:
- Model number: RMC3
- Inductor: Low noise
- RFI Filtering: Yes
- EMI Filtering: Yes
- Current draw: <10 mA
- AC adapter requirements: 5.5/2.1mm coax plug with a negative center post, 9VDC AC regulated Class II, 20mA to 200mA max current output.

The RMC3 is developed and hand-built by Geoffrey Teese, featuring fuzz- friendly technology, EMI resistant inductor, heavy-duty true-bypass on/off switch, exclusive 100K RMC-ICAR potentiometer, Switchcraft jacks, easily adjustable rocker tension, and AC adapter jack. It is covered by a limited one-year warranty.

The pedal is housed in a standard-sized black case topped with a black footpad. The US MSRP is $255, and specifications are subject to change without notice.
